Cutting Machine

Reciprocating hand-held power central drive T-type double-driving wheel lawn mower. This machine is suitable for flat grasslands in agricultural/pastoral areas and mountain and hilly grasslands. It is mainly used for lawn trimming, forage harvesting, pastoral management, shrub trimming, etc. The engine is a four-stroke air-cooled gasoline engine, which is started by a rebound starter. Smooth transmission, no energy loss. Environmental protection design, in line with Euro II emission standards. The output of the gearbox adopts a special clutch to realize stepless speed change. The cutter is moved by the roller mounted on the crank of the eccentric wheel directly driving the sliding groove on the blade. The eccentric wheel mechanism is connected with the power output belt at the front end of the chassis transmission box through a first-level belt transmission, and the clutch adopts a combined tooth clutch. The reciprocating cutter clutch control, throttle switch control, and emergency flameout switch control are all set on the operating armrest. The handle can be adjusted up and down in the vertical direction. The cutting blade is made of special chrome steel. It has good wear resistance and can pass through the blade gap. Adjust the shim of the blade presser. The cutter guide is accurate and stable. In order to increase the traveling adhesion, the tire adopts herringbone rubber wheels. The transmission mechanism is equipped with a protective cover, which is safe to use. The machine has the advantages of wide application, stable operation, low power consumption, good cutting quality, no jamming, etc.
It also can applied for cutting sorghum, rice, corn these crops with stem.
